2027 Ford Super Duty: Trims, Specs, Towing, and What's New
The 2027 Ford Super Duty reaches up to 40,000 lbs of towing capacity with the 6.7L High-Output Power Stroke diesel. The diesel produces 1,200 lb-ft of torque at 1,600 rpm, a figure no competitor in the class matches. This page covers every trim, spec, and capability number, with in-stock units available at Arrow Ford in Abilene.
What's New for 2027
The headline number for 2027 is 40,000 lbs of maximum available towing on the F-450 DRW with the 6.7L High-Output Power Stroke diesel and the 40k Gooseneck Tow Package. That puts the Super Duty in a class of one for conventional pickup trucks.
Ford also updated the Ford Co-Pilot360 2.0 driver-assist suite to a standard inclusion on more configurations, and the SYNC 4 system now centers on a 12-inch display across the lineup. The Ford Connectivity Package, which bundles Alexa Built-in and one year of unlimited Wi-Fi hotspot access, is now more broadly available across trims. Off-road buyers gain Trail Turn Assist on configurations equipped with the XL Off-Road 35-inch package and Rock Crawl Mode on Tremor, FX4, and XL Off-Road builds.
The 2027 model year also formalizes the available power take-off (PTO) provision on the TorqShift transmissions, a key addition for utility and vocational buyers who need onboard power delivery.
Trim Lineup
The 2027 Super Duty spans the F-250, F-350, and F-450 series, each offered in multiple cab and box configurations. Trims run from XL through Platinum.
XL
XL is the workhorse entry point for the F-250, F-350, and F-450. It includes the 7.3L gas V8 (F-250/F-350), blind-spot alert, rear view camera, rear parking sensors, and stability and traction control as standard. The F-450 XL runs the 6.7L diesel as standard.
XLT
XLT adds a step up in interior comfort without abandoning the truck's commercial usefulness. Available on F-250 Regular Cab, F-250 Crew Cab, F-350 Super Cab, F-350 Super Cab (higher wheelbase), and F-450, this trim layers in more connectivity options and available 4x4.
Lariat
Lariat is where the Super Duty shifts from working truck to all-day comfort without sacrificing any towing or payload numbers. Available on F-250, F-350, and F-450.
King Ranch
King Ranch brings premium leather, unique exterior badging, and standard 4x4 on F-250, F-350, and F-450. Both gas and diesel engines remain available.
Platinum
Platinum sits at the top of the lineup on F-250, F-350, and F-450 with standard 4x4, the highest-output alternator setup (dual 410-amp on diesel), and the fullest tech and comfort package the Super Duty offers.
Performance and Powertrain
Two proven engines power the 2027 Super Duty.
The 7.3L 2V DEVCT NA PFI V8 gas is standard on F-250 and F-350. It produces 420 hp at 5,350 rpm and 445 lb-ft of torque at 4,250 rpm. It pairs with the TorqShift-G 10-speed automatic, which includes Selectable Drive Modes: Normal, Eco, Slippery Roads, and Tow/Haul. Recommended fuel is 87 octane. The 7.3L is not compatible with E85.
The 6.7L High-Output Power Stroke V8 Turbo Diesel is available on F-250 and F-350, and standard on F-450. It delivers 500 hp at 2,600 rpm and 1,200 lb-ft of torque at 1,600 rpm. It pairs with the TorqShift 10-speed SelectShift automatic and is rated for B20 biodiesel. The diesel's variable geometry turbocharger with charge air cooler and compacted graphite iron block are designed for long-haul durability.
Maximum payload reaches 7,900 lbs on properly configured F-350 DRW builds. On the F-350 Regular Cab 4x2 with the gas engine and the Heavy-Duty Payload Package, payload tops out at 7,900 lbs. Super Duty towing and payload specs
Fuel capacity varies by configuration: 29 gallons (diesel, shorter wheelbase), 34 gallons (most configurations), or 48 gallons (Crew Cab long wheelbase). Drive choices cover 4x2 and 4x4 across all series.
Key Super Duty Capability Specs
| Category | 2027 Ford Super Duty Specification |
|---|---|
| Maximum Towing | Up to 40,000 lbs with F-450 DRW, 6.7L High-Output Power Stroke diesel, and 40k Gooseneck Tow Package |
| Maximum Payload | Up to 7,900 lbs on properly configured F-350 DRW builds |
| Gas Engine | 7.3L 2V DEVCT NA PFI V8 gas, 420 hp and 445 lb-ft of torque |
| Diesel Engine | 6.7L High-Output Power Stroke V8 Turbo Diesel, 500 hp and 1,200 lb-ft of torque |
| Transmission | TorqShift 10-speed automatic or TorqShift 10-speed SelectShift automatic, depending on engine |
| Series | F-250, F-350, and F-450 |
Interior, Comfort, and Cargo
The Super Duty Crew Cab offers 131.9 cubic feet of total passenger volume with up to 6 occupants. Front headroom measures 40.8 inches, shoulder room is 66.7 inches, and front leg room reaches 43.9 inches. In the rear of the Crew Cab, leg room is 43.6 inches, which is competitive with midsize SUVs.
The Super Cab rear seat provides 33.5 inches of rear leg room and 40.3 inches of headroom, a practical choice for work crews who need occasional rear passenger capacity without the length of a full Crew Cab.
Cargo behind the first row ranges from 10.9 cubic feet in the Regular Cab to 53.4 cubic feet in the Crew Cab. The cargo box itself offers two size options. The 6.75-foot box delivers 65.6 cubic feet of volume with an inside length of 81.9 inches at the floor. The 8-foot box steps up to 78.7 cubic feet and 98.1 inches at the floor. Width between wheelhouses is 50.5 inches on both.
Upper trims add premium seating materials, and the King Ranch and Platinum grades bring leather-trimmed interiors suited for both job site and highway miles.
Technology and Infotainment
Every 2027 Super Duty centers on a 12-inch touchscreen running SYNC 4. The system supports wireless phone connectivity, and the Ford Connectivity Package adds Alexa Built-in plus one year of unlimited Wi-Fi hotspot service.
Available Connected Navigation delivers live traffic routing, and a head-up display is available on upper trims to keep critical information in the driver's sightline.
The available 360-degree camera system is a significant upgrade for buyers maneuvering trailers, fifth wheels, or gooseneck loads in tight quarters. Tow/Haul drive mode is standard, and Trail Control (cruise control for off-road situations) is available with off-road packages.
The Ford Security Package, included for one year, provides theft alerts and start inhibit for job site or overnight parking situations. An available PTO provision on the transmission adds live-drive power takeoff capability for utility equipment.
Safety and Driver Assistance
Standard safety equipment on the 2027 Super Duty includes dual front airbags, front head curtain airbags, front side airbags, stability control, traction control, blind-spot alert, rear view camera, rear parking sensors, tire pressure monitoring, child door locks, and LATCH child seat anchors.
Ford Co-Pilot360 2.0 is available as an upgraded driver-assist suite. Specific systems within that package include pre-collision assist, lane-keeping features, and automatic emergency braking, consistent with Ford's Co-Pilot360 2.0 offering. Ford Co-Pilot360 2.0 system details
Off-road safety systems include Trail Control for low-speed technical terrain, Rock Crawl Mode on Tremor, FX4, and XL Off-Road package trucks, and Trail Turn Assist on XL Off-Road 35-inch package builds.
The basic warranty covers 3 years or 36,000 miles bumper to bumper. The powertrain warranty extends to 5 years or 60,000 miles, and the diesel powertrain warranty reaches 5 years or 100,000 miles. Corrosion (perforation) coverage runs 5 years with unlimited mileage.
Who the 2027 Super Duty Is For and How It Compares to the Prior Year
The 2027 Super Duty is the right choice for buyers who need real towing numbers, not marketing approximations. Contractors hauling heavy equipment trailers, ranchers running gooseneck loads, and fleet buyers who need PTO capability all find a confirmed spec here, not a theoretical one.
Compared to the prior model year, the 2027 update sharpens the tech story with broader Co-Pilot360 2.0 availability and a more accessible Connectivity Package. The 40,000-lb gooseneck ceiling on the F-450 reinforces that the Super Duty is the ceiling in its segment.
Buyers moving from a gas-only prior-year Super Duty will notice the diesel's 1,200 lb-ft figure most directly. That torque arrives at just 1,600 rpm, which means the truck pulls at low speed without needing to rev hard, a meaningful difference when loaded on a grade.
For Abilene buyers who work on job sites, farms, or haul through the wide-open stretches of West Texas, the 2027 Super Duty's payload and tow ratings match those demands without compromise.
Put a 2027 Super Duty to Work from Arrow Ford in Abilene
Arrow Ford carries the 2027 Super Duty across trims and configurations. Whether the job calls for an F-250 XL for a work crew or an F-450 Crew Cab DRW for maximum gooseneck towing, the inventory in Abilene covers the range. Browse current stock, value a trade-in, or schedule a test drive today.
Frequently Asked Questions
What is the maximum towing capacity of the 2027 Ford Super Duty?
The 2027 Super Duty tows up to 40,000 lbs when the F-450 DRW is equipped with the 6.7L High-Output Power Stroke diesel and the 40k Gooseneck Tow Package.
What engines are available in the 2027 Ford Super Duty?
Two engines are available. The 7.3L V8 gas engine (420 hp, 445 lb-ft) is standard on F-250 and F-350. The 6.7L High-Output Power Stroke V8 turbo diesel (500 hp, 1,200 lb-ft) is available on F-250 and F-350 and standard on F-450.
What is the maximum payload on the 2027 Super Duty?
The 2027 Super Duty reaches up to 7,900 lbs of payload on the F-350 DRW Regular Cab 4x2 with the gas engine and the Heavy-Duty Payload Package.
What trims does the 2027 Ford Super Duty come in?
The 2027 Super Duty is offered in XL, XLT, Lariat, King Ranch, and Platinum across the F-250, F-350, and F-450 series. Cab choices include Regular Cab, Super Cab, and Crew Cab depending on series and trim.
Does the 2027 Super Duty have standard blind-spot monitoring?
Yes. Blind-spot alert is standard on the 2027 Super Duty lineup.
What warranty does the 2027 Ford Super Duty carry?
The basic warranty covers 3 years or 36,000 miles. Powertrain coverage extends to 5 years or 60,000 miles. The diesel powertrain warranty reaches 5 years or 100,000 miles. Corrosion perforation coverage is 5 years with unlimited mileage.
Can I get the 2027 Super Duty with off-road capability?
Yes. Available packages including FX4, Tremor, and XL Off-Road add features such as Rock Crawl Mode, Trail Control, and Trail Turn Assist (on the XL Off-Road 35-inch package).
Where can I buy a 2027 Ford Super Duty near Abilene, TX?
Arrow Ford in Abilene carries the 2027 Super Duty. Browse available inventory online today.
